| moostang51, Comment for image # 10419 | 10 Jan 09 16:45 |
| Have to p.m. James so he can create a Top Flight Spitfire Mk IX category. Tomorrow the center section and then 63" ws. bird appears. |
| moostang51, Image # 10419 | 10 Jan 09 16:40 |
Second wing section. Once the blue tape begins to show the wing former, using a finer grit now will bring the basswood spars and trailing edges flush w/o cutting binto the balsa. |
| moostang51, Image # 10110 | 07 Dec 08 13:33 |
A little more rounding on the elevator leading edge will get me to the specified throws required. Robart hinge points perform nicely. |
| moostang51, Image # 10109 | 07 Dec 08 13:29 |
A strip of 1/32" plywood recessed at trailing edge will hide elevator gap and eliminate some flutter. |
| moostang51, Image # 10108 | 07 Dec 08 08:31 |
Oh too bad. Mother natures' surprise will force me to stay in today and work on the Spit. He-he-he...... |
| poppy, Comment for image # 10027 | 30 Nov 08 03:54 |
| Happy belated bday, moos. You have yourself a challenging build here. |
| moostang51, Comment for image # 10027 | 29 Nov 08 17:17 |
| The 5/32" brass tube shown will be used to cut out a recess for the elevator collar rod into the front of the elevator. I will install a 1/32" plywood strip recessed at the rear of the stab to hide the soon to be rounded edge of the elevators. Tomorrow should be a busy day. |
| moostang51, Image # 10027 | 29 Nov 08 17:10 |
hit the big 52 today, actually it hit me. Sneaking in a little time for elevator assembly. Robart hinge point hinges and 1/8" metal tie-in laid out for drillling tomorrow. |
| Xanadu, Comment for image # 9996 | 27 Nov 08 21:46 |
| Got me an older Top Flite P-40 Warhawk kit off eBay, 60" wingspan. |
| John M Oshust, Comment for image # 9999 | 27 Nov 08 20:36 |
| Very professional....nice work! |
| wingspanner, Comment for image # 9996 | 27 Nov 08 18:23 |
| Class act. I hopw you will do me the honour of an idiots guide to the building and set up. I've just ordered my first RC build. An Aerodrome rc Sopwith pup. |
| moostang51, Comment for image # 9996 | 27 Nov 08 12:52 |
| James, could you please create a spot for this in my hangar. Much appreciated, Moostang. |
| moostang51, Image # 9999 | 27 Nov 08 12:50 |
Rudder assembly. I drilled lots of lightening holes in this and the stabilizer frame prior to covering with 1/16 skin. |
| moostang51, Image # 9998 | 27 Nov 08 12:46 |
Initial shaping and sanding complete. Will fit for hinge points and store away. |
| moostang51, Image # 9997 | 27 Nov 08 12:44 |
Scouring e-bay, found some retracts. Learning to fly on a simulator. This one will fly someday. |
| moostang51, Image # 9996 | 27 Nov 08 12:43 |
Being built in unison with other Guillow's already started. Top Flite Spitfire MkIX. |
